Highlights
- The world’s brightest and most versatile cap lamp
- Dual-Beam technology
- Light output: 10,000 Lux (15,000 Lux in Dynamic Turbo Bright mode)
- Run time: 13 hrs minimum
- Intrinsically safe (IS) approvals pending
- Lightweight, compact and rugged
- IP67
- Flexible hardhat mounting options – fixed and adjustable clips
- Serviceable battery and components
- 2-year warranty
- Multiple charger configuration options (single, 4-unit, 10-unit, 24-unit and 48-unit)
- Any NLT charging infrastructure can be retrofitted for the Polaris Plus
- Anti-theft locking device
- Vehicle charger
Dual-Beam Features
The Polaris Plus features three beam pattern options plus a Low-Light Setting:
- Focused Spot – NLT’s traditional beam pattern
- Wide-Angle Flood Light – a flat, even light; ideal for close-up work
- Dual-Beam – combines both beam patterns to provide a center spot with great peripheral lighting
- Low-Light Setting – reduces light output when needed (access Low-Light Setting by holding button down for one second)
Dynamic Turbo Bright
- an added feature that increases light output in any of the three beam patterns by 40% for up to five minutes (access Dynamic Turbo Bright by holding button down for three seconds)
NEW! Introducing the NLT Automated Cap Lamp Output Tester for cap lamps and flashlights.
Test and log your lamp’s output in less than 10 seconds.
Specifications
|
Battery Charge Time: |
< 10 hours |
|
Run Time: |
Main LED > 13 hours |
|
Emergency Flashing: |
Activated with 5-second hold down |
|
Weight: |
170g (6oz) |
| Light Output: | 10,000 Lux / 15,000 Lux with Dynamic Turbo Bright |
|
Charger Configuration: |
Single, 4, 10, 24 and 48-unit; 12 VDC adapter for vehicle connection |
|
Charger Power Source: |
120V or 240V models |
|
Charging Temperature: |
5°C to 35°C (optimum 15°C to 20°C) |
|
Water and Dust Protection: |
IP67 |
|
Approvals: |
Intrinsically safe (IS) approvals pending |
Resources
Data Sheet – English
The battery and all components of each NLT cap lamp is serviceable, increasing the life of the lamp, lowering the total cost of ownership and ultimately reducing waste. Check with your authorized NLT distributor or NLT for service or training.
Accessories
Locking Device
NL8058
- This locking device is designed for use with all-in-one-cap lamps
Adjustable Locking Clip
NL0329
- Adjustable clip with a security locking feature to prevent cap lamp from falling out of the hard hat bracket
Mini Adjustable Magnetic Clip
NL0312
- An adjustable clip with a magnet so the lamp can be attached to any metallic surface
Adjustable Clip Small
NL0328
- Adjustable clip with a security locking feature to prevent cap lamp from falling out of the hard hat bracket
Adjustable Magnetic Clip
NL0314
- An adjustable clip with a magnet so the lamp can be attached to any metallic surface
- Attaches easily to most hard hats
Standard Adjustable Clip
NL0302
- Allows the user to adjust the angle of the light beam
- Attaches easily to most hard hats
Fixed Mounting Clip
NL8005
- Cap lamp is designed so that the angle of the light shines in the normal working areas at all times and there is no need to pivot the lamp
NLT Breakaway Lanyard
NL8602
- Adjustable and detachable lamp lanyard with an aluminum swivel hook
NLT Lanyard
NL8606
- 3.8′ (.95 cm) flat breakaway lanyard with swivel hook
Neck Strap
NL8605
- Heavy duty lanyard designed with a heavy duty neck strap for maximum comfort
- For use with all-in-one lamps
Cap Lamp Headband
NL8604
- An adjustable elastic headband designed for use with all-in-one cap lamps
Dust Protector
NL7807-P10
- Keep dust and debris off your lenses with these tear-away protectors
- Pack of 10
Lamp Pouch
NL8601
- Protect your investment with this pouch designed for all-in-one cap lamps
- Black with NLT logo
Tripod Mounting Bracket
NL8038
- Fits all NLT cap lamps with any clips
- Features a universal mounting bracket
- Connects to all GorillaPods and most other tripods
Small Magnetic GorillaPod
NL8610
- Small magnetic GorillaPod stays connected to your lamp, leaving your hands free
- Over two dozen leg joints that bend and rotate, giving you flexibility
- Super strong magnetic feet
Large Magnetic GorillaPod
NL8609
- Large magnetic GorillaPod stays connected to your lamp, leaving your hands free
- Over two dozen leg joints that bend and rotate, giving you flexibility
- Rubberized ring and foot grips
Warranty
Northern Light Technologies (NLT) guarantees that Eclipse*, Polaris, Polaris Plus, Genesis*, Genesis Plus*, Rebel and Rebel Plus cap lamps, and related charging systems, will be free of material and workmanship defects for a period of 24 months from the serialized date on the product.
Messenger, Eagle* and Falcon* cap lamps, and related charging systems, and the NLT Automated Cap Lamp Output Tester will be free from defects in material and workmanship for a period of 12 months from the serialized date on the product.
Excluded from the warranty are items or components that are considered to be prone to high wear, such as: rubber components, cables, strain reliefs, covers, lenses and clips.
This warranty does not apply to NLT product performance due to the installation or integration of non-approved third-party components or solutions, such as, but not limited to tracking tags.
This warranty is conditional upon the proper use, maintenance, operation, charging and protection according to instructions within NLT User Guides.
NLT’s responsibility for any loss or damages, regardless of cause, shall not exceed, under any circumstances, the original purchase price of the product to the original purchaser.
*Tag warranty is based on that offered by the 3rd-party solution provider.
Non-Warranty Repairs Policy
NLT will repair any product that is outside the Warranty Policy under the following conditions:
- All returns must be approved by an NLT customer service representative in advance through the issuance of a Return Goods Authorization (RGA) number. Equipment returned without an RGA number will be subject to an administration surcharge of $50.00,
- Equipment returned to NLT with no fault found will be subject to a minimum troubleshooting charge of $10.00 per piece of equipment, plus shipping and handling,
- Refused estimates or units that are uneconomical to repair are subject to a minimum troubleshooting charge of $10.00 per unit,
- Troubleshooting charges may be applied as a discount to replacement purchases if made within 30 days,
- Repaired or replaced components are further warranted for 1 year from the repair date excluding high-wear components as detailed above.
